Epomaker TH80 Pro Keyboard Shortcuts
Epomaker TH80 Pro Connection Modes
Bluetooth Pairing - Device 1: Fn + 1 (hold 3-5s) — Hold until the indicator on the 1 key flashes fast in blue. Search for 'TH80 BT5.0' on your Bluetooth device and connect. Flashing stops when paired.
Bluetooth Pairing - Device 2: Fn + 2 (hold 3-5s) — Hold until the indicator on the 2 key flashes fast in blue. Pairs with a second Bluetooth device independently from Device 1.
Bluetooth Pairing - Device 3: Fn + 3 (hold 3-5s) — Hold until the indicator on the 3 key flashes fast in blue. Pairs with a third Bluetooth device independently.
Switch Bluetooth Devices: Fn + 1/2/3 (short press) — Quickly press Fn + 1, 2, or 3 to switch between previously paired Bluetooth devices without re-pairing.
2.4GHz Wireless Mode: Fn + 4 (hold 3-5s) — Hold until the 4 key indicator flashes green. Insert the 2.4G USB dongle into your device. Flashing stops when connected. Lower latency than Bluetooth.
Switch to Wired USB Mode: Fn + 5 — Press until the 5 key lights up in white. Connect USB-C cable for wired mode with zero latency and simultaneous charging.
Epomaker TH80 Pro OS Switch
Switch Between Win/Mac Mode: Knob (in OS submenu) — Use the rotary knob to switch between Windows and macOS mode. This swaps the modifier key layout and changes Fn layer shortcuts to match each OS.
Epomaker TH80 Pro Fn Layer - Windows
Screen Brightness Down: Fn + F1 — Decrease display brightness.
Increase Effect Speed: Fn + → — Speed up the current lighting animation effect.
Decrease Effect Speed: Fn + ← — Slow down the current lighting animation effect.
Epomaker TH80 Pro Layer & Status
Switch Fn Layer: Fn + Z/X/C — Switch between FN1, FN2, and FN3 layers. Each layer can have different Fn key mappings configured via the Epomaker software.
Check Layer & Mode Status: Fn + Space — Hold to display which layer (Z/X/C indicator) and connection mode (1/2/3/4/5 indicator) the keyboard is currently using.
Check Battery Level: Fn + B — Hold to display battery percentage. Keys 1-0 light up proportionally (e.g., 1-6 lit = 60%, all lit = 100%).
Epomaker TH80 Pro Special
Lock/Unlock Windows Key: Fn + Win — Toggle the Windows key on/off to prevent accidental activation during gaming.
Knob - Media Control: Rotate Knob — Rotate the knob for volume control (default). The knob function can be changed via submenus to control brightness, zoom, or other programmable actions.
