Drop ALT Keyboard Shortcuts
Drop ALT Fn Layer - Function Keys
F1 - F10: Fn + 1-0 — Access standard function keys F1 through F10 by pressing Fn with the corresponding number row key.
F11: Fn + - — Output standard F11 key.
F12: Fn + = — Output standard F12 key.
Drop ALT Fn Layer - Navigation
Print Screen: Fn + P — Output Print Screen key for screenshots.
Scroll Lock: Fn + [ — Output Scroll Lock key.
Pause / Break: Fn + ] — Output Pause/Break key.
Backtick / Tilde: Fn + Esc / Fn + Shift + Esc — Output backtick (`) with Fn+Esc or tilde (~) with Fn+Shift+Esc, since Esc replaces the backtick position on this 65% layout.
Drop ALT LED Controls
Next LED Pattern: Fn + D — Cycle forward through available RGB lighting patterns/effects.
Previous LED Pattern: Fn + A — Cycle backward through available RGB lighting patterns/effects.
Increase LED Brightness: Fn + W — Increase the overall RGB brightness level.
Decrease LED Brightness: Fn + S — Decrease the overall RGB brightness level.
Increase Pattern Speed: Fn + E — Speed up the current scrolling/animated LED pattern.
Decrease Pattern Speed: Fn + Q — Slow down the current scrolling/animated LED pattern.
Toggle Breathe Effect: Fn + Tab — Toggle a breathing animation overlay on the current LED pattern.
Toggle Pattern Direction: Fn + CapsLock — Reverse the scrolling direction of the current LED pattern.
Toggle LEDs On/Off: Fn + X — Turn all RGB LEDs on or off completely.
Toggle LED Zone Mode: Fn + Z — Cycle through LED illumination zones: Keys + Edge underglow, Keys only, or Edge underglow only.
Drop ALT Media Controls
Volume Up: Fn + PgUp — Increase system volume.
Volume Down: Fn + PgDn — Decrease system volume.
Mute: Fn + Del — Mute/unmute system audio.
Drop ALT Firmware & Configuration
Drop Configurator / QMK: Connect USB → open Drop Configurator — Use the Drop Configurator web app to remap keys, change LED patterns, and flash custom firmware. Also supports compiling custom QMK firmware for advanced users.
Enter DFU / Bootloader Mode: Fn + B (or physical reset button) — Enter Device Firmware Update mode for flashing new firmware via the Drop Configurator or QMK Toolbox. The keyboard disconnects and re-enumerates as a DFU device.
